Asynchronous serial adalah komunikasi dimana kedua pihak (pengirim dan penerima) masing-masing menghasilkan clock namun hanya data yang ditransmisikan, tanpa clock. Agar data yang dikirim sama dengan data yang diterima, maka kedua frekuensi clock harus sama dan harus terdapat sinkronisasi.

Now if you open your Arduino serial monitor at a baud rate of 9600, you’ll see a message appearing in your window saying “HI!” every 1 second. Schematics (3.3V FTDI Programmer), follow the next schematics to establish a serial communication between your FTDI programmer and your ESP8266 to upload some code. Downloading ESPlorer IDE I recommend using the ESPlorer IDE which is a program created by 4refr0nt to create and save Lua files into your ESP8266. Follow these instructions to download and install ESPlorer: • to download ESPlorer • Unzip that folder • Go to the main folder • Run ESPlorer.jar • Open the ESPlorer (as shown in the Figure below). Writing Your ESP8266 Script Copy and paste the code below into ESPlorer IDE window. -- Rui Santos -- Complete project details at ledOn = 0 pin=4 gpio.mode(pin,gpio.OUTPUT) uart.on('data', 3, function(data) print('Received from Arduino:', data) if data=='HI!'

Chertezhi arochnogo angara. /video/3157116-ustanovka-protivotumannyh-far-na-prioru-svoimi-rukami-video/ 2. /video/-uborka-posle-remonta-v-spb/ 3. Caron New York, located in Midtown Manhattan, was established as a key resource for professionals, parents and adolescents, as well as the recovering community which includes Caron alumni who have completed drug or alcohol rehab living in the New York region. Door: Ryanorocks|, 00:50:24 comment4, otvety_na_godovye_kontrolnye.

Then if ledOn==0 then ledOn = 1 gpio.write(pin,gpio.HIGH) print('LED On') else ledOn = 0 gpio.write(pin,gpio.LOW) print('LED Off') end end end, 0). Summary: The ESP is configured to listen to serial communications. Every time that receives the string “HI!” at a baud rate of 9600, it will turn the GPIO 2 on or off.

Uploading Your Script When you open the ESPlorer IDE you should see a window similar to the preceding Figure, follow these instructions to send commands to your ESP8266: • Connect your FTDI programmer to your computer • Set bad raute as 9600 • Select your FTDI programmer port (COM3, for example) • Press Open/Close • Select NodeMCU+MicroPtyhon tab • Copy the your Lua script into ESPlorer Then you simply click the button Save to ESP and save your file with the name “init.lua”. Everything that you need to worry about or change is highlighted in red box in the following Figure. Final Circuit Follow the next schematics to complete this tutorial. Note: I’m using a voltage divider to shift the TX signal of the Arduino from 5V to 3.3V.

This works well for slow baud rates, but it might not work at faster baud rates. For more information about lowering the voltage of signals. Demonstration Now your LED should be blinking every one second. This means that your Arduino is sending the string “HI” and your ESP is receiving that data. Watch the video at the beginning of this post for a live demonstration. Now instead of sending a string saying just “HI!”, you can attach sensors to your Arduino and send that data to your ESP instead.

Later you can that displays that data. Read Next You might also find interesting trying one of these tutorials: • • • Do you have any questions? Leave a comment down below!
